Textura™ GROOVE
Textura GROOVE panels provide long, parallel runs of bamboo ridges that are milled into a solid bamboo substrate. Available in 3 different profiles and 9 different colors, your seamless, and sustainably harvested ‘grooved’ bamboo wall is literally a pin nail away from reality. Can be installed vertically or horizontally.
Ribs
| Individual Ridge Width | 17mm (~ 2/3”) |
| Individual Groove (i.e., Valley) Width | 8.5mm (~ 1/3”) |
| Panel Width | 140mm (~ 5 1/2″) |
| Panel Length | 8′ *Customizable up to 19′ |
| Panel Thickness | ~ 18mm (~ 3/4”) |
Mesa
| Individual Ridge Width | ~ 5mm, 21mm (~ 3/16”, 13/16”) |
| Individual Groove (i.e., Valley) Width | ~ 9mm (~ 3/8”) |
| Panel Width | 140mm (~ 5 1/2″) |
| Panel Length | 8′ *Customizable up to 19′ |
| Panel Thickness | ~ 18mm (~ 3/4”) |
Plateau
| Individual Ridge Width | ~ 35mm (~ 1 3/8”) |
| Individual Groove (i.e., Valley) Width | ~ 11mm (~ 7/16”) |
| Panel Width | 140mm (~ 5 1/2″) |
| Panel Length | 8′ *Customizable up to 19′ |
| Panel Thickness | ~ 18mm (~ 3/4”) |
Click image to view product brochure.
Ready to Order?
Lead time and shipping costs vary by product. If you are ready to place an order, CLICK HERE to get a quote for your Textura Recycled project.
Features
- Panels seamlessly abut adjacent panels for visual continuity.
- Available in multiple colorways to accentuate design.
- Standard and simple installation methods
- Class A fire-rating (ASTM E84-17)
Product Documentation
- Care and Maintenance
- CSI Specification
- Installation Instructions
- Material Safety Data Sheet (MSDS)
- Warranty
Installation Method
- pin nail, adhesive, or ‘Z’ clip
Finish
- All colors available either in a UV Lacquer (‘satin’ sheen) or ‘rubbed’ Oil (matte’ sheen)
Composition
- Bamboo – 100% Bamboo
